C:\nv_flash\OLD\nvflash_ka_Version>nvflash -i1 new.rom
NVIDIA Firmware Update Utility (Version 5.670.0)
Copyright (C) 1993-2020, NVIDIA Corporation. All rights reserved.
Checking for matches between display adapter(s) and image(s)...
Adapter: Graphics Device (10DE,2484,1028,3907) S:00,B:09,D:00,F:00
EEPROM ID (EF,6014) : WBond W25Q80EW 1.65-1.95V 8192Kx1S, page
WARNING: Firmware image PCI Subsystem ID (10DE.146B)
does not match adapter PCI Subsystem ID (1028.3907).
Please press 'y' to confirm override of PCI Subsystem ID's:
Overriding PCI subsystem ID mismatch
Current - Version:94.04.25.40.72 ID:10DE:2484:1028:3907
GPU Board (Normal Board)
Replace with - Version:94.04.25.00.2B ID:10DE:2484:10DE:146B
GPU Board (Normal Board)
Update display adapter firmware?
Press 'y' to confirm (any other key to abort):
EEPROM ID (EF,6014) : WBond W25Q80EW 1.65-1.95V 8192Kx1S, page
Executing automatic disable of EEPROM write protect...
Remove EEPROM write protect complete.
Storing updated firmware image...
[==================================================] 100 %
Verifying update...
Update successful.
Firmware image updated.
- New version: 94.04.25.00.2B
- Old version: 94.04.25.40.72
InfoROM image updated.
- New version: G001.0000.03.03
- Old version: G001.0000.03.03
Setting EEPROM software protect setting...
Setting EEPROM protection complete.
A reboot is required for the update to take effect.
