Figure 3-2: The Router’s Front Panel
NOTE: SecureEasySetup is a feature that makes it
orange when the Router is powered on. The color orange indicates that the Router is not using
(Cisco logo) Orange/White. The Cisco logo is the Router’s SecureEasySetup button. It lights up and will stay
easy to set up your wireless network. If you have
the SecureEasySetup feature, while the color white indicates that the Router is using the
SecureEasySetup devices, run the Router’s Setup
SecureEasySetup feature. When the Router enters SecureEasySetup mode, the Cisco logo will Wizard CD-ROM and follow the on-screen
turn white and start flashing. After the Router has generated the SSID and WPA-PSK (also instructions to use SecureEasySetup.
called WPA-Personal) key, the Cisco logo will stop flashing and stay white.
To clear the SSID and WPA-PSK key, press and hold down the Cisco logo for five seconds. The
Cisco logo will flash slowly as the Router resets itself. The Cisco logo will turn orange to
indicate a successful reset.
